| Basic Information | ||
| Supported CPU | Supports 10th Gen Intel Core and Pentium Gold / Celeron processors for LGA 1200 socket | |
| Chipset | Intel B460 | |
| BIOS | 1x 128 Mb flash UEFI AMI BIOS Multi-language |
|
| Form Factor | Miro-ATX Form Factor 9.3 in. x 7.6 in. (23.6 cm x 19.2 cm) |
|
| Expansion Slots | ||
| PCI | 1x PCIe 3.0 x16 slot 2x PCIe 3.0 x1 slots |
|
| M.2 Socket | 1x M.2 slot (Key M) Supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices |
|
| Memory | ||
| Type | Dual-Channel Architecture | |
| Slots | 2x DDR4 memory slots | |
| Supported Memory | Intel Core i7/ i9 Supports up to DDR4 2933 MHz Intel Core i5 and below Supports up to DDR4 2666 MHz Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP) |
|
| Maximum Memory | 64GB | |
| Graphics | ||
| Graphics | 1x DVI-D port, supports a maximum resolution of 1920x1200 @60Hz 1x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @30Hz |
|
| Max Shared Memory | 1GB | |
| Connector & Ports | ||
| HDMI | 1x HDMI 1.4 port, maximum resolution of 4096x2160 @30Hz | |
| DVI-D (s) | 1x DVI-D port, maximum resolution of 1920x1200 @60Hz | |
| USB (s) | Intel B460 Chipset 6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 3.2 Gen 1 5Gbps connector) 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors) |
|
| LAN Port (s) | 1x Realtek 8111H Gigabit LAN controller | |
| Supported Storage | Intel B460 Chipset 6x SATA 6Gb/s ports 1x M.2 slot (Key M) Supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices Intel Optane Memory Ready Supports Intel Smart Response Technology for Intel Core processors |
|
| Audio | Realtek ALC892 Codec 7.1-Channel High Definition Audio |
|
| Internal I/O Ports | 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 6x SATA 6Gb/s connectors 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x USB 3.2 Gen1 5Gbps connector (supports additional 2 USB 3.2 Gen1 5Gbps ports) 1x 4-pin CPU fan connector 1x 4-pin system fan connector 1x Front panel audio connector 2x Front panel connectors 1x Serial port connector 1x Chassis Intrusion connector 1x Clear CMOS jumper 4x EZ Debug LED |
|
| TPM (Trusted Platform Module ) | 1x TPM module connector | |
| Warranty Information | ||
| Manufacturing Warranty | 03 Years Warranty | |
| Others | ||
| Special Features | Intel B460 Chipset Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices |
|
