৳12300
| Basic Information | ||
| Supported CPU | Supports 1st, 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics / Athlon with Radeon Vega Graphics and A-series / Athlon X4 Desktop Processors for Socket AM4 | |
| Chipset | AMD A320 Chipset | |
| Form Factor | 8.9 in. x 7.4 in. (22.6 cm x 18.7 cm) m-ATX Form Factor |
|
| Expansion Slots | ||
| PCI | 1 x PCIe 3.0 x16 slot Supports x16 speed with 1st, 2nd, and 3rd Gen AMD Ryzen processors Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics processors Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors 1 x PCIe 2.0 x1 slots |
|
| Memory | ||
| Type | Dual channel memory architecture | |
| Slots | 2 x DDR4 memory slots | |
| Supported Memory | upport 1866/ 2133/ 2400/ 2667(OC)/ 2933(OC)/ 3200(OC)+ MHz | |
| Maximum Memory | 64GB | |
| Graphics | ||
| Graphics | 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz 1 x HDMI port 1.4, supports a maximum resolution of 4096x2160@30Hz |
|
| Max Shared Memory | GraphicssMaximum shared memory of 2048 MB | |
| Connector & Ports | ||
| HDMI | 1 x HDMI port 1.4, supports a maximum resolution of 4096x2160@30Hz | |
| DVI-D (s) | 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz | |
| USB (s) | AMD A320 Chipset 6 x USB 3.2 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal connectors) 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal connectors |
|
| LAN Port (s) | 1 x Realtek 8111H Gigabit LAN controller | |
| Supported Storage | AMD A320 Chipset 4 x SATA 6Gb/s ports Supports RAID 0, RAID 1 and RAID 10 |
|
| Audio | Realtek ALC892 Codec 7.1-Channel High Definition Audio |
|
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x USB 3.2 Gen1 connector (supports additional 2 USB 3.2 Gen1 ports) 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 1 x Serial port connector 2 x Front panel connectors 1 x Chassis Intrusion connector 1 x Clear CMOS jumper |
|
| TPM (Trusted Platform Module ) | 1 x TPM module connector | |
| Warranty Information | ||
| Manufacturing Warranty | 03 Years Warranty | |
